VELLEMAN HPS10VELLEMAN
HPS10 — Digital Storage Personal Scope 10MS/s
Order Code: hps10
Manufacturer: VELLEMAN
The Velleman Personal Scope is not a graphical multimeter but a complete
portable oscilloscope at the size and the cost of a good multimeter. Its high
sensitivity - down to 0.1mV/div - and extended scope functions make this unit
ideal for hobby, service, automotive and development purposes. Because of its
extreme value for money, the PersonalScope is well suited for educational use in
schools and colleges. Suitable for measurements on audio equipment, mains
voltage applications, digital signals, all kind of sensors, signal analysis in
automotive applications, car stereo, etc. Its full auto setup function, makes
measuring waveforms very easy.
Features:
- includes battery charging circuit
- power supply: 5 x 1.5V AA batteries
Optional equipment available:
- practical holster: BAGHPS (not included)
- Hard Shell Carrying Case: CASEHPS (not included)
- AC Power Adapter 9V - 500mA: PS905USA (not included)
- 5 x 1.5V AA battery or Nicd / NiMH (not included)
Specifications:
- 10MHz sampling rate
- 0.1mV sensitivity
- up to 2MHz analogue bandwidth
- 5mV to 20V/div in 12 steps
- 200ns to 1hour/div time base in 32 steps
- full auto set up
- trigger mode: run, normal, once, roll, slope +/-
- X and Y position signal shift
- DVM readout with x10 option
- audio power calculation (rms and peak)
- dBm, dBV, DC, rms ... measurements
- signal markers for Volt and Time
- frequency readout (through markers)
- recorder function (roll mode)
- signal storage (2 memories)
- LCD: 128x64 pixels / high-contrast
- up to 20h on alkaline batteries

IMAGES ARE FOR REFERENCE ONLY
Please note that manufacturers often change color, labeling and packaging
without notice. If there is a change in functional specifications, Electronics
N More will update our information as soon as possible.
